Speed Dry Mix - Grout M50 ( Gun Grade)
Cementitious Pourable Gun Grade Non-shrink High Strength Grout. Available in 40 / 25 kg bag, in dry form; No curing is required after application.
Speed Dry Mix – Grout M50 ( Gun Grade) is supplied as a ready to use dry powder. It is a blend of Portland cement, graded fillers (clay free) and chemical additives which impart controlled expansion in the plastic state at minimal water demand. The low water demand and special additives ensures high early strength. The graded fillers are designed to assist uniform mixing and produce a consistent grout.
STANDARD COMPLIANCE
ASTM C1107 (Standard Specification for Packaged Dry, Hydraulic-Cement Grout (Non-shrink)
RAW MATERIALS
Main Binder | Ordinary Portland Cement |
Aggregate | Graded Fine Aggregates (Max. Size of Aggregate: 1 mm ); silt free |
Admixtures | a) High Water Reducing Agent ( Chemical admixture) b) Anti bleeding Compound c) Re-dispersible powder ( Adhesion related) d) Self Curing Compound e) Accelerator |
FEATURES
- Non- metallic
- Non – shrink
- Low Water Demand
- High Strength
- Designed as a Pourable Gun Grade Variant
- Durable
- Self Curing
APPLICATION
- Tie rod hole filler of shear walls (Aulform)
- Conduit filling
- Filling gaps between Beam soffit and masonry wall / Panels
- Repair of Concrete honeycombing / patchwork
COMPRESSIVE STRENGTH
Consistency | Water /Powder ratio | Compressive Strength, N/mm2 | |||
1 Day | 3 days | 7 days | 28 days | ||
Pourable – Gun Grade | 0.15- 0.17 | 20-18 | 32-28 | 42-38 | 62-58 |
PRODUCT DATA
Color | Grey |
Dry Density | 1550 -1650 Kg/CuM |
Wet Density | 1800 – 1900 Kg/CuM |
Water / Powder Ratio | 0.15 to 0.17 |
Flow @ 30ºC | 90- 110 mm |
Pot Life | 45 – 60 mins |
Initial Setting Time | 130 -170 mins |
Final Setting Time | 240 – 270 mins |
Shelf Life | 12 Months |
SURFACE PREPARATION
Surface must be free of dust, loose particles, grease, mould oil , rust metal, wood peels etc. Holes and Fixing pockets must be blown clean of any dirt/ loose particles or debris . Substrate or the area where Grouting application is done must be in SSD condition .
MIXING AND APPLICATION
- 15-17% of water (by weight of material) is required for mixing.
- Mixing must be done with mechanical mixer / stirrer.
- Normally mixing takes about 2 minutes. Once Mix is ready, it should be consumed well within 60 minutes
CURING
No water curing is required post application.
STORAGE AND PACKING
Speed Dry Mix – Grout M50 ( Gun Grade)is supplied in dry form and delivered in 40/25 Kg bag.
Storage life is 12 months if the product is stored in a dry place.
HEALTH AND SAFETY
Recommended to wear NIOSH approved or equivalent particulate face mask when mixing the material.
- Material contains cement, which may produce allergic effect.
- Keep out of reach of children.
- Avoid contact with eyes and prolonged contact with skin.
DISCLAIMER: It is assumed that all standard Civil Engineering Practices shall be adopted for application of this Grout. The information given in this leaflet is for general guidance only. As product is helpful in different applications, you can reach our Technical Cell on 040-40045009 or speed @speeddrymix.com for clarifications/ queries, if any.
